Specification:
| Model No. | JAGUAR N300 |
| Number of heating zones | 2 |
| Length of heating zones | 1200mm |
| Body size | 2800(L)*1250(W)*1560(H) |
| Outside dimension | 3600(L)*1250(W)*1560(H) |
| Weight | 1000KG |
| Total/running power | 16KW/6KW |
| Air supply | 0.5MPa |
| Preheating method | IR(standard)/Hot air |
| Preheating power | 220V 6KW |
| Control method | PC +PLC/Touchtone/Touch screen |
| Range of temp. control | Room temperature---300ºC |
| Preheating time | About 10-15mins for setting 150ºC |
| Solder type | Lead-free / Sn-Pb |
| Solder pot capacity | 280KG |
| Solder pot temperature | 300ºC |
| Solder power | 380V 8KW |
| Solder temp. control method | PID&SSR |
| Wave crest drive power | 1KW 220V |
| Warm-up time of solder | About 120mins for setting 250ºC |
| PCB width | 50-300mm |
| Convey speed | 300-1800mm/min |
| Convey direction | L→R (R→L optional) |
| Convey angle | 4-7 º |
| Flux pressure/capacity | 3-5 bar/6L |
INTRODUCTION
1.Efficient,energy-saving,lead-free, environment-friendly,safe and
brand-new design,simple operation,convenient maintenance.
2.Automatic power system, frequency converter control, automatic
board input system.
3.Flux sprays system using scanning spray nozzle,Japanese nozzles
and rodless pneumatic cylinders and PLC control, accurate and
reliable.
4.Preheating system uses 3-stage powerful air system, excellent
heat preservation, temperature warm-up, temperature uniformity, no
more than ±2ºC.
5.Special alloy transportation chain claws, non-stick tin,
reinforced, and ensures the quality of welding PCB board.
6.Tin stove adopts imported high frequency conversion motor
independent control, stable performance.
7.Lead-free solder furnace with independent design, environment
protection and safety, easy to clean
8.Tin heating furnace uses high-speed PID and 2-stept indepent
outer-heating control, warm-up quickly and eliminates the flaws of
stove tin explodes.
9.With time controller, can preset switch functions, tin stove
machine heating picks up in 90minutes.
10.With black box memory function, can always get at production
management records, improve work efficiency.
11.Reasonable design of environment protection, and automatic
washing claw, ensure the cleanliness of claws.
12.The design is reasonable and safe with sensitive fault alarm
system, to ensure the stable performance the safety of operators.
