SMT Lead Free Convection Reflow Oven manufacturer
Specification:
| Model | JAGUAR M6 |
Heating System | Number of heating zones | UP 6/BOTTOM6 |
| Number of cooling zones | 1 |
| Length of heating zones | 2500MM |
| Heating mode | hot air |
| Cooling Mode | Force air |
Conveyor System | Max. Width of PCB | 350mm |
| Mesh belt width | 400mm |
| Transmission Direction | L→R(or R→L) |
| Transmission Net Height | 880±20mm |
| Transmission type | Mesh and chain |
| Range of rail width | 0-300mm |
| Conveyor speed | 0-1500mm/min |
| Auto/manual Lubrication | standard |
| Upper hood method | Manual(option:auto) |
| Fixed rail side | Front rail fixed(option: rear rail fixed) |
| Components high | Top and bottom 25mm |
Control system | Power supply | 5line 3phase 380V 50/60Hz |
| Total power | 28kw |
| Starting power | 28kw |
| Normal power consumption | 4KW |
| Warming time | About 20 mins |
| Temp. setting range | Room temperature-300℃ |
| Temp. control method | PID close loop control & SSR driving |
| Temp. control precision | ±1℃ |
| Temp. deviation on PCB | ±2℃ |
| Data storage | Process Data and status storage(80GB) |
| Nozzle plate | Aluminum Alloy Plate |
| Abnormal Alarm | Abnormal temperature. (extra-high/extra-low temp.) |
| Board dropped alarm | Tower light: Yellow-warming, Green-normal, Red-abnormal |
General | Dimension(L*W*H) | 3600×1000×1490mm |
| Weight | 700KG |
| Color | Computer gray |
Features:
1.The heating system is unique , advanced and long-life.
2.High efficiency and energysave nickel cauterize heating pipe is
used in heating system(replacement within one year), strong hot air
cycle structure , making PCB and components heating equally, high
efficiency and rapid heating speed.
3.The intelligent microcomputer precision controller (replacement
within one year), through intelligent operation of PID, control
heating automatically , temperature controlling function can detect the changing of temperature, and then make inner temperature stable by controlling. Modular design , easy to repair
and assembly.
4.Import high temperature and high speed motor are used (replacement within one year), stable operation,small tremble and low noise.The efficiency be improved greatly, extending the using time.
The heating system use import components to make sure high
stability and reliability of all system.
5.Reliable and stable transmission system, stable operation driver,
and the speed range is 0-2000mm/min.
6.stable operation special stainless steel net chain is durable and wearable. So it didn’t need to be change for a long time that can save cost.
7.Stable and reliable electronic controller system.
8. Computer is option.
